Teltonika FMC130 – Advanced 4G GPS Tracker with Multi-Accessory Support
Advanced 4G LTE Cat 1 tracker with flexible inputs. Requires an active subscription plan — from €4.99/device/month or €47.90/year.
- Most versatile hardwired tracker – supports a huge range of accessories and sensors
- Anti-theft immobilizer – remotely cut the engine if the vehicle is stolen (via DOUT)
- Driver identification – connect RFID readers or iButton for driver authorization
- Advanced fuel monitoring – impulse input reads fuel flow meter data with high accuracy
- Three configurable outputs – run buzzer, alarm lights, door lock, immobilizer and custom scenarios
- Triple network fallback – 4G LTE Cat 1, 3G UMTS and 2G GSM for maximum coverage
- Negative input – saves installation time when connecting factory accessories (doors, seatbelt, alarm)
- CAN data support – reads vehicle CAN data with external Teltonika CAN adapters
- Bluetooth 4.0 + LE – connects to temperature/humidity sensors, beacons, OBDII dongle, headset
- Internal antennas – no external antenna wires visible in the vehicle
- Backup battery – continues tracking if main power is cut
- Jamming detection – alerts you if someone tries to block the GPS or cellular signal
- Remote firmware updates – FOTA WEB over-the-air updates
- Cellular 4G LTE Cat 1, 3G UMTS/HSPA, 2G GSM/GPRS fallback
- GNSS GPS, GLONASS, GALILEO, BEIDOU
- GNSS receiver sensitivityUp to –165 dBm
- Power input10 – 30 V DC
- Backup battery Internal Li-Ion (170 mAh)
- Digital inputs4 (1 negative input, 2 impulse inputs)Digital outputs3 configurable (immobilizer, buzzer, alarm, door lock, etc.)
- Analog inputs2Interfaces1-Wire,
- Bluetooth 4.0 + LE, USB
- CAN support Via external Teltonika CAN adapter
- Antennas Internal high-gain GNSS and LTE (no external antennas)
- SIM Micro-SIM (included, preconfigured)
- Sleep modes GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep
- Configuration FOTA Web, FOTA, Teltonika Configurator (USB/Bluetooth), FMBT
- Installation Hardwired (professional installation recommended)
- Ideal for Fleet management, logistics, car rental, construction, mining, agriculture, emergency services
Product Description
The FMC130 device comes already with a SIM card and is fully preconfigured — just buy it, connect it to your vehicle following the included manual, and start tracking through the Track Vision app. This is our most flexible hardwired tracker and the perfect choice for fleet managers who need more than basic location tracking. On top of real-time GPS, the FMC130 lets you connect a wide range of accessories thanks to its rich set of inputs and outputs: door sensors, seatbelt detection, alarm buttons, temperature sensors, fuel flow meters, RFID/iButton driver identification, remote engine immobilizer, buzzer, alarm lights and remote door lock. With three configurable digital outputs you can trigger advanced scenarios like stolen-vehicle recovery (remote engine cut-off), panic alarms, or custom automations. Its impulse input enables highly accurate fuel monitoring via fuel flow meters — making it the ideal solution for cranes, construction vehicles, mining equipment, agricultural machinery and other high fuel consumption assets. With 4G LTE Cat 1 plus 3G and 2G fallback, connectivity is rock-solid anywhere in the world. Through the Track Vision app you get real-time tracking, trip history, geofencing, crash detection, driver behaviour reports, driver ID logs, fuel consumption monitoring, immobilizer control and instant alerts — everything a professional fleet operator needs in one device.
